CATALOGUE
DES ECROUS DE TUYAUX
SATMO MECA
| Mise à jour
le 20/06/00 |
 |
| Réf |
A |
B |
C |
D |
E |
F |
G |
| 28500 |
1/2x20
UNF |
- |
6 |
14 |
16 |
5,5 |
- |
| 28501 |
1/2x20
UNF |
10,9 |
8 |
14 |
22 |
6 |
4 |
| 28502 |
1/2x20
UNF |
10,9 |
6,5 |
14 |
22 |
6 |
4 |
| 28503 |
M12x100 |
10 |
6,5 |
14 |
22 |
6 |
4 |
| 28504 |
M12x100 |
10 |
6,5 |
14 |
21 |
6 |
2 |
| 28505 |
1/2x20
UNF |
10,7 |
6,1 |
14 |
22 |
6 |
4 |
| 28506 |
7/16x20
UNF |
- |
6,5 |
11 |
15 |
5 |
- |
| 28507 |
3/8x24
UNF |
8 |
5,2 |
10 |
16 |
4 |
1,5 |
| 28509 |
1/2x20
UNF |
- |
8,2 |
14 |
17 |
6 |
- |
| 28510 |
7/16x20
UNF |
- |
6,5 |
12 |
19 |
5 |
- |
| 28512 |
7/16x20
UNF |
9,2 |
4,9 |
12 |
19 |
5 |
2,5 |
| 28514 |
M10x125 |
8 |
5 |
10 |
19 |
4 |
3 |
| 28516 |
3/8x24
UNF |
8 |
6,5 |
10 |
19 |
4 |
3 |
| 28516A |
3/8x24
UNF |
8 |
5 |
10 |
19 |
4 |
3 |
| 28516B |
3/8x24
UNF |
8 |
4* |
10 |
19 |
4 |
3 |
| 28517 |
M10x100 |
8 |
5 |
10 |
19 |
4 |
3 |
| 58518 |
M14x150 |
12 |
10,2 |
16 |
23 |
6 |
3 |
| 28520 |
M12x100 |
10 |
5 |
14 |
22 |
5 |
3 |
| 28521 |
7/16x20
UNF |
9,2 |
6,5 |
12 |
24 |
5 |
3 |
| 28522 |
1/2x20
UNF |
10 |
5 |
14 |
22 |
5 |
3 |
| 28523 |
3/8x24
UNF |
8 |
5 |
10 |
24 |
4 |
3 |
| 28524 |
M12x125 |
- |
6,2 |
14 |
18 |
6 |
- |
| 28527 |
M10x100 |
8 |
5 |
11 |
24,5 |
4 |
2,9 |
